HMI Repair Services

S7 Automation offers you the option to repair your Human Machine Interface (otherwise known as HMIs) and LCDs. All our repairs are done by highly skilled technicians and our work is backed by a 2 Year Warranty. When you choose S7 Automation for your HMI repair services you can save up to 60%.

When it is possible to repair rather than replace something it saves time and money too. Repairing an existing system saves on the cost of purchasing a new system, but it also saves time because there is no need for training operators on a new system. Another thought to consider is that often when an HMI system is changed, many other items may need to be modified as a result. This can become like a domino effect and cost an operation a significant amount of money. At S7 Automation, the HMI Repair technicians can troubleshoot and repair down any HMI up to the component level. With over 20 years of repair experience, we are well versed in keeping HMI systems repaired and functioning at a high level.

VFD – Frequency Drives Repair Services

Our team repairs AC and DC drives from all the major manufacturers and supplies our customers quality workmanship. All of our repairs are done by highly skilled technicians and our work is backed by a 2 Year Warranty.

We isolate any discovered problems, will repair your drive and do a full load test to ensure the quality of the repair and test function the drive.

We can load test Drives rated from 1/4 horsepower to 500 horsepower. By repairing your drive with us, you can save up to 60% versus buying new.

Drives we can repair:

• AC Drives
• DC Drives
• Soft Starts
• Motor Controls
• Inverters Drive Boards
• And More

We repair industrial automation components. The repair price is always fixed in advance and usually ranges from 20 to 40% of the original price of a new product. Most common repairs are done in 2-4 weeks, in urgent cases we offer an express repair in a shorter period.

At the same time, we also offer the possibility of testing parts in our service center. When testing a product, it will be evaluated in a simulated situation whether the product works as it should.

Contact our team to request a quote for a repair .

SIEMENS Simatic S7

Simatic S7 is a modular mini PLC system, which during its development established completely new standards in the field of industrial automation. Its advantages will be appreciated by small production companies as well as complex production plants. Simatic S7 is financially advantageous and user-friendly. Thanks to its resistance to shocks and vibrations, Simatic S7 can be used without problems even in industries with difficult production conditions.

A wide range of modules can be used to expand the system and thus create a central or decentralized structure.

Our services:

• Siemens Simatic S7 system sale,
• Siemens Simatic S7 parts sale,
• repairs Siemens Simatic S7,
• purchase of used and non-functional components Siemens Simatic S7.

S7200

Main features:

• Modular machines for undemanding technologies
• Large selection of CPU types with different performances
• A large selection of modules
• Option to expand up to 7 modules
• System bus integrated into the modules
• Possibility of communication via RS485 or Profibus communication interfaces
• No slot restrictions – the possibility of combining modules
• Custom programming software – MicroWin
• A single power supply for the CPU and all modules
• Micro PLC with integrated functions

S7200 modules

EM expansion modules:

• Digital input: 24V DC, 120/230V AC
• Digital output: 24V DC, Relay
• Analog inputs: Voltage, Current, Resistance, Thermocouples
• Analog outputs: Voltage, Current

S7300

Main features:

• Modular machines for medium-demanding technologies
• Large selection of CPU types with different performances
• A large selection of modules
• System bus integrated into the modules
• Possibility of connection to industrial networks:
  1. MPI (Multipoint interface),
  2. PROFIBUS
  3. Industrial Ethernet
• Single PG connection with access to all modules
• No slot restrictions – the possibility of combining modules
• Build configuration and parameter setting using “HW Config” tool (part of Step7)

S7-300: Modules

SM signal modules:

• Digital input: 24V DC, 120/230V AC
• Digital output: 24V DC, Relay
• Analog inputs: Voltage, Current, Resistance, Thermocouples
• Analog outputs: Voltage, Current

IM interface modules:

• IM360 / IM361 and IM365 allow multi-line configurations of PLC assembly
• They create a connection from one rack to the next, connecting the modules with a single bus

Dummy modules DM:

• The DM370 filler module reserves a slot, for example, for an SM module for which parameters have not yet been determined. Or to reserve a slot for later installation of the IM module

Functional modules:

• They ensure complex control processes: Pulse counters, Positioning, Feedback regulation

Communication Processors (CPs):

• They provide connections to these communication systems:
  1. PtP (Point-to-Point)
  2. PROFIBUS
  3. Industrial Ethernet

S7400

Main features:

• Powerful modular machines for medium to highly demanding technologies
• Large selection of CPU types with different performances
• A large selection of modules
• Possibility of expansion up to 300 modules
• System bus integrated into the modules
• Possibility of connection to industrial networks:
  1. MPI (Multipoint interface),
  2. PROFIBUS
  3. Industrial Ethernet
• Single PG connection with access to all modules
• No slot restrictions – the possibility of combining modules
• Build configuration and parameter setting using “HW Config” tool (part of Step7)

Multiprocessor mode – the possibility of installing up to 4 CPUs in one rack

S7400-modules

SM signal modules:

• Digital input: 24V DC, 120/230V AC
• Digital output: 24V DC, Relay
• Analog inputs: Voltage, Current, Resistance, Thermocouples
• Analog outputs: Voltage, Current

IM interface modules:

• The IM460, IM461, IM463 and IM467 modules allow connecting different racks:
  • UR1 – universal rack, max. 18 modules
  • UR2 – universal rack, max. 9 modules
  • ER1 – expansion rack, max. 18 modules
  • ER2 – expansion rack, max. 9 modules

Functional modules:

• They ensure complex control processes: Pulse counters, Positioning, Feedback regulation

Communication Processors (CPs):

• They provide connections to these communication systems:
  1. PtP (Point-to-Point)
  2. PROFIBUS
  3. Industrial Ethernet

Programming device – PG

Industrial notebook SIMATIC Field PG:

The Field PG programming device is intended for programming and servicing of small control microsystems SIMATIC S7 S7-200 and S7-1200, larger control systems S7-300, S7-400, S7-1500 and SIMATIC S5, decentralized peripherals, visualization, drives and next …

• A mobile programming device with a powerful processor designed for industrial use
• Optimal for commissioning, service and maintenance of automation systems
• Industrial notebook with wireless technology, large widescreen display, long battery life, high speed RAM
• The device hardware contains the necessary converters and interfaces for connecting control systems via TTY, PPI, MPI, Profibus, Ethernet), programming EPROM, FEPROM, MMC memories
• In addition to the service interfaces, the device is equipped as standard with other common interfaces like a notebook and can be used as such
• Hardware and software equipment is optional according to the configuration offered
• The device can be supplied with Win XP Prof., Windows 7 Ultimate 32/64 bit, the choice of OS depends on the type of SW used

Simatic S71200

The SIMATIC S7-1200 control units from Siemens are the intelligent choice for a compact automation solution with extended communication options and integrated technological functions. They are available in standard and secure versions.

SIMATIC S7-1200 controllers are the ideal choice when it comes to flexible and efficient execution of automation tasks in the low to medium power range. They are characterized by a comprehensive range of technological functions and integrated communication, as well as a particularly compact and space-saving design. The SIMATIC S7-1200 can be tailored to almost any industrial application thanks to wide expansion options. The integrated PROFINET interface ensures a perfect interplay of other elements of automation technology in the unified TIA Portal engineering environment. The modular concept of the control system facilitates its expansion, moreover, without changing its physical dimensions

Simatic S71200-modules

CPU – High speed I/O

On the SIMATIC S7-1200 you will find up to 6 high-speed inputs and 2 high-speed outputs. Three high-speed inputs, which are integrated on the base unit – CPU, can be used for frequencies up to 100 kHz. The high-speed outputs can be used for controlling stepper motors or for PWM pulse width modulation with a maximum frequency of 100 kHz. By inserting signal modules, we get high-speed inputs/outputs that allow us to work with frequencies up to 200 kHz!

CPU – Signal modules

One signal module can be inserted into all types of SIMATIC S7-1200 CPUs and thus expand the number of digital and analog inputs/outputs without increasing the space occupied in the cabinet. It serves as a supplement to the integrated I/O on the base unit. These are modules that can be inserted directly into the basic units of the S7-1200 series. Siemens currently offers analog, digital input and output signal modules, modules for connecting thermocouples and resistance sensors, RS485 communication module

Signal cards

Signal cards can be used to expand the number of digital and analog inputs/outputs on the base unit. Signal cards are connected from the right side of the CPU and their number depends on the type of CPU. The CPU 1211 allows no signal card to be connected, the CPU 1212 two and the CPU 1214 up to eight signal cards.

Simatic S7-1500 – HW description

• PM modules
  • Supplying modules (connected loads)
  • Wire connection to IO module terminals
• PS module
  • System bus power supply
  • Connection via U-connector, diagnostics
  • The installation of the PS module is not necessary if power supply via the CPU is sufficient, if the PS module is installed the CPU does not need to be powered

CPUs up to 1513 have only one Profinet CP

CPUs from 1515 onwards have multiple Profinet interfaces. Only the first PROFINET interface (X1) supports PROFINET and isochronous Real Time (IRT) communication. The IP subnets of both interfaces must be different.

Example:

• subnet mask of both interfaces: 255.255.255.0
• IP address of the first interface: 192.168.0.10
• IP address of the second interface: 192.168.1.10

CPU with display

• Each S7-1500 PLC with display
• Two sizes depending on PLC type
• It has its own order number and can also be ordered as a spare part, with a lifetime of 50,000 hours of operation
• PLC can run without it (ordinary cover as a spare part)
• Can be connected, disconnected during operation, PLC remains in RUN mode

Simatic ET 200SP – PLC description

Simatic ET 200SP – Description PLCSIMATIC ET 200SP is a multifunctional distributed I/O system for a wide range of applications. Thanks to the scalable design, you can adapt the I/O station exactly according to local requirements. SIMATIC ET 200SP is designed with IP 20 protection and is intended for installation in a switchboard

I/O system SIMATIC ET 200SP and its main advantages:

• Decentralized Periphery
• Compact design
• High performance
• Fast communication (Profinet)
• Support for AS-i and IO-Link interfaces
• The station can be expanded to up to 64 modules (depending on the interface module)
• Module and terminal block can be hot swapped during operation
• Minimum space required in the cabinet (suitable for standard 80 mm cabinets)

Simatic ET 200SP – Modules 1

• BusAdapter of the SIMATIC ET 200SP bus
• Some SIMATIC ET 200SP interface modules have a universal PROFINET interface for bus adapters. With the appropriate BusAdapter, the connection type can be adapted to the requirements of the respective application.
• Interface module IM 155
• Interface modules connect the ET 200SP station to the bus system of the automation environment. Modules with a PROFINET interface from basic to high-speed functions or a High Feature interface module for the proven PROFIBUS bus are available.
• CPU – Distributed control unit based on SIMATIC ET 200SP
• The ET 200SP CPU distributed control units combine compactness and flexibility. Especially in the medium performance range for machines with distributed intelligence or serial machines with limited space, distributed controllers are the perfect solution for standard and secure applications. Based on the particularly compact design of the ET 200SP, there are two alternative CPU variants: Open PC-based controller with software PLC or CPU with classic PLC function of the S7-1500 series. CPU Standard, Failsafe CPU, Technology CPU and Failsafe Technology CPU versions available when using Open Controller or between CPU Standard and Failsafe in two performance classes when using an S7-1500 based solution.

Simatic ET 200SP – Modules 2

I/O Modules

A comprehensive range of I/O modules is available for the ET 200SP, including Fail-safe versions. Peripheral modules are marked with different colored squares to easily identify the type of module:

• Digital input module (DI) 8/16 channels color coding: white
• Digital output modules (DQ) 4/8/16 channels color coding: black
• Analog input modules (AI) 4 channels color coding: light blue
• Analog output modules (AQ) 2/4 channels color coding: dark blue
• Technology modules (TM) color coding: turquoise
• Communication modules (CM) color coding: light gray
• Special color coding modules: mint green
• Motor starters such as on-line direct starters (DS) and reverse starters (RS)
• Tire

In addition to the color codes of the module types, safety modules are marked with a yellow case and an “F-” prefix on the plain text label.

Base Units

There are several types of base units available. Combinations of I/O modules with Base Units / interface modules or PC configurators are possible www.siemens.com/et200sp or in the SW tool “TIA Selection Tool”

Server Module

It closes the ET 200SP bus. The module includes slots for 3 spare fuses (5 × 20 mm).

Simatic ET 200SP – Function class

In ET200SP applications, there are a number of modules distinguished by “Function class” that affect application and expansion possibilities. Below is an overview of the various ET200SP hardware components, what their different functional classes are, and what applications these classes apply to.

Each module has a two-letter notation on the front, reflecting one of the four function classes to which the module belongs. The different feature classes listed below reflect increasing levels of functionality and extensibility:

Interface Modules (IMs)

• Basic (BA): allows expansion to up to 12 modules, 2x ethernet port, works with all except Fail-safe modules, allows operation with gaps
• Standard (ST): same features as basic IM, with the added ability to support up to 32 modules, Fail-safe hardware, IP 67 environment and single hot swapping
• High Feature (HF): same functions as standard IM, with additional ability to support up to 64 I/O modules, flexible connection via Bus adapters, 250 μs isochronous operating mode and multi hot swapping
• High Speed (HS): allows expansion of up to 30 modules with the additional ability to support 125 μs isochronous operating mode.

I/O Moduly

• Basic (BA): basic diagnostics and functions
• Standard (ST): adjustable through parameterization, module-based diagnostics, faster data processing
• High Feature (HF): channel-based diagnostics, additional operating modes and functions
• High Speed (HS): isochronous operating mode, highest data processing speed

Logic module LOGO! 0BA8

The most common areas of use

• Simple remote monitoring and control.
• Home installation – control of lighting, heating, air conditioning, windows or irrigation.
• Automatic irrigation, automated feeding systems in agriculture.
• Remote monitoring and control of small machines.
• Basic energy monitoring.

LOGO! 0BA8 and its main advantages

• A compact, easy-to-use and inexpensive solution for simple inspection tasks.
• Easy to operate, universally applicable without accessories.
• “All in one”: Integrated display and control panel.
• 36 different functions can be connected at the push of a button or via PC software.
• LOGO! 8: 38/43 different functions can be connected at the push of a button or via PC software.
• Functions can be easily changed at the touch of a button. No more time-consuming switching.

Parameters of the LOGO! 0BA8

Basic module 0BA8

• 8 digital inputs (DI) – can be expanded to a maximum of 24 digital inputs.
• 4 digital outputs (DO) – can be expanded to a maximum of 20 digital outputs.
• 8 analog inputs (AI).
• 8 analog outputs (AO).
• Compared to older versions of modules, 0BA8 has many improvements including design.
• A more user-friendly display that has a larger interface with 6 lines that can fit 20/24 characters.
• There is a new option to change the display color (to white, orange and red)
• All basic modules have an integrated web server.
• Possibility of using an external Micro CF card (up to 20,000 records).
• External control via any smart device such as a mobile phone or tablet.
• All basic modules have an Ethernet interface for communication with LOGO! 8, LOGO! TDE, SIMATIC PLC, SIMATIC Panels and PC computers.

LOGO! basic modules with display

Four basic modules with display

• 12/24 RCE: 12/24V DC, relay outputs 10A, 4 inputs usable as AI (0-10V)
• 24 CE: 24V DC, transistor outputs, 4 inputs usable as AI (0-10V)
• 24 RCE: 24V AC/DC, relay outputs 10A
• 230 RCE: 115-240V AC/DC, relay outputs 10A

Basic features and functions

• All basic modules with an integrated web server
• Temperature range -20° to +55°C
• NTP server/client pro přesný datum a čas
• Integrated Modbus TCP client/server
• LOGO! Access Tool for downloading data to Excel

LOGO! basic modules without display – LOGO! Pure

Because some specific applications do not require operator controls or interface elements such as buttons or a display, Siemens provides LOGO! 12 / 24RCEo, LOGO! 24RCEo, LOGO!24CEo and LOGO! 230RCEo version without display.

Versions without a display offer you the following benefits

• Even more cost-effective without a control element.
• It requires less rack space than conventional hardware
• Very easy to use
• Protected access
• Compatible with LOGO! version with display
• It offers the possibility to read data using SW LOGO!Soft Comfort

!LOGO extension modules

Expansion modules for connection to LOGO! basic module

• Digital DM8: 4 DI / 4 DO (different voltages)
• Digital DM16: 8 DI / 8 DO (different voltages)
• Analog AM2: 2 analog inputs 0-10V, 0-20mA, 4-20mA
• Analog AM2 RTD: 2 analog inputs for PT100 / PT1000 temperature sensors
• Analog AM2 AQ: 2 analog outputs 0-10V, 0-20mA, 4-20mA

Text display module – LOGO! HERE

Main features of LOGO! HERE

• It features a wider display area than LOGO! with display: 6 lines, 20 characters each.
• It contains four programmable cursor keys, four programmable function keys, an ESC key and an ENTER key.
• 3 switchable background colors to highlight different types of messages.
• From the Ethernet interface on the right side of the LOGO! The TDE connects with an Ethernet cable to the LOGO! Ethernet interface. Basic module.
• Requires 12V DC or 24V AC/DC power supply.

Additional components of LOGO!

LOGO! CMR 2020 / 2040

• Communication module for GSM/GPS
• Remote control LOGO! by SMS
• Symbolic messages
• Sending emails
• Remote access using open VPN
• GPS location tracking
• Time synchronization
• Programming via web server
• CMR2020 for GSM / GPRS mobile wireless networks
• CMR2040 for LTE mobile wireless networks

LOGO! CMS

• Switch with 4 ports
• One switch from the front
• Industrial Ethernet network 10/100 Mb/s
• Topology: linear, tree, star
• Voltage ranges: 12/24V DC or 230V AC/DC

LOGO! Power

• Flat power supply for switchboards
• 11 devices: 5V, 12V, 15V and 24V DC up to 100 W
• New: 12V / 0.9A and 24V / 0.6A
• High energy efficiency

LOGO! CMK2000

• Integration into the KNX system
• Communication between LOGO! and an intelligent house
• Programming with ETS
